1.Introduction The full name of LCD is Liquid Crystal Display. The properties of liquid crystals were discovered in 1888 by Austrian chemist Friedrich Reinitzer. After decades of research, in 1964, George H. Heilmeier at the U.S. Radio Corporation laboratory completed the first dynamic scattering mode liquid crystal display. In 1971, International Liquid Xtal Company began mass production of the first liquid crystal display using a twisted nematic field-effect. Starting in the 1980s, liquid crystal displays began to become truly popular, with several types of LCDs such as TFT, UFB, TFD, and STN emerging. 2.The Structure The structure of an LCD consists of a liquid crystal layer placed between two parallel glass substrates. The lower glass substrate is equipped with TFT (Thin Film Transistor), and the upper glass substrate has a color filter. By controlling the alignment of liquid crystal molecules through the signals and voltages applied to the TFT, the polarization of light can be controlled for each pixel, achieving the display function. LCD is a substance that exists between solid and liquid states; it does not emit light on its own and requires an external light source to function. The number of light tubes affects the brightness of the LCD.

1.What is TFT-LCD? TFT-LCD,which stands for Thin Film Transistor Liquid Crystal Display, is an active matrix liquid crystal display technology. It is widely used in various electronic products due to its advantages such as low power consumption, high clarity, and color display. However, it also has some "inherent shortcomings" : • Limited viewing Angle • Slow response speed (due to the limitation of the LCD rotation speed) • Dynamic images are prone to blurring • Limited operating temperature range Terms related to TFT LCD: LC: Liquid Crystal CF:Color Filter B/L: Back light L/G: Light Guide  data line scan line 2.The internal structure of TFT-LCD panels · Polarizing filter: Located at the top and bottom layers of the display, it is responsible for controlling the polarization direction of light, ensuring that only light in a specific direction can pass through. · Liquid Crystal Cell (LC Cell): The core component, which contains liquid crystal molecules. These molecules are controlled by an electric field to regulate the passage of light. · Color Filter (CF): Located above the liquid crystal unit, it is used to generate color images. Each pixel point corresponds to red, green, and blue colors. · Glass substrate: The glass substrate serves as the core carrier material for the color filter. · Thin-film transistor (TFT): Located beneath the color filter, it is used to control the switch of each pixel, enabling precise display of images.  · Printed Circuit Board (PCBA): Connects and controls various components to ensure the normal operation of the entire display. · Light Guide: Located within the backlight module, it is used to evenly distribute the light from the lamp tube, providing a uniform backlight effect. · Lamp tube: Provides the backlight source to ensure that the display can clearly show images even in a dark environment.

The working principle of the driver board is to receive and convert signals. How does the driver board transmit the display signal? As shown in the diagram below, when the power button is pressed and the computer screen lights up, the display signal has been successfully transmitted. The transmission process involves three main components: the computer graphics card, the driver board, and the display panel. The signal starts from the output interface of the computer’s graphics card, then enters the input interface of the driver board. The chip on the driver board receives the signal and, based on the panel data stored in the chip, converts the image signal into a display signal, which is then output to the display panel. In this process, the driver board converts the signal provided by the graphics card into a signal that can be accepted by the display panel, with the transmission protocol changing from HDMI to eDP. In simple terms, the process of display signal transmission involves the signal starting from the computer, passing through the driver board for conversion, and then entering the display panel. During this signal conversion process, only the form of signal transmission is changed; the driver board cannot alter the signal's resolution or refresh rate. For example, if a 1080p signal comes in through the HDMI interface, it will also exit through the eDP interface as 1080p, and the image displayed on the panel will be 1080p. Even if the panel supports a maximum resolution of 4K, if the video signal entering the panel is 1080p, the final image displayed will still be 1080p.

During the production process of PCBA boards, improper operation by personnel or material quality issues often lead to defective PCBA boards. In such cases, the defective boards need to be repaired. Today, let's introduce the detailed process of PCBA board repair. Visual Inspection of PCBA: This step involves checking the PCBA board for any visible defects from the production process, such as: short circuits, cold solder joints, missing components, reversed component polarity, and damaged components. Measure All Power: The main task here is to measure whether the power source has a short circuit to ground. Power-on Test for Defects: After powering up, use a testing fixture to double-check for defects. Repair Based on Defective Phenomenon: The repair is carried out according to the defect symptoms and circuit principles. The repair work can refer to the repair operation guidelines provided by engineering. Self-check After Repair: After the repair, the repaired section needs to be self-checked. This includes checking for short circuits, cold solder joints, solder balls, solder dross, and the appearance of solder joints. Test Fixture Check: Use a test fixture to check whether the PCBA board is repaired properly. Visual Full Inspection: Perform a full inspection on the repaired product. By repairing defective PCBA boards, the number of scrapped boards can be reduced, which helps lower the factory's production costs.
